High-Temperature Solar Selective Coating Development for Power Tower Receivers
Sandia National Laboratories (SNL), under the National Laboratory R&D competitive funding opportunity, is developing, characterizing, and refining advanced solar-selective coatings with high solar-weighted absorptivity (α > 0.95) and low emittance (ε < 0.40) for concentrating solar power (CSP) power tower receivers that can operate in air at temperatures ≥ 650°C without degradation for ≥10,000 cycles. These performance qualities are required for the next-generation receivers that must reach the SunShot Initiative's annual average thermal efficiency target of 90% and cost target of $150/kWth or less.
The research team is exploring materials with high melting temperatures, intrinsic oxidation resistance, high thermal conductivity, and low vapor pressure. The team is performing the following steps:
- Conduct durability testing of candidate materials deposited on receiver metal substrates in conventional thermal furnaces, solar simulators, and on-sun systems to understand the degradation mechanisms and improve stability under realistic simulated environments.
- Apply successful coatings to tubular receivers and test the coatings on-sun as part of an integrated demonstration.
- Model these coatings for power tower applications and deposit them by physical vapor deposition, spin coating, thermal spray, and electro-deposition.
- Characterize the optical performance, material properties, and temperature stability.
- Consider surface modification techniques for performance enhancement and continue exploring lower-cost deposition methods for promising material systems that have been identified.
- Investigate novel multi-layered coatings predicted by models developed at NREL. A thermal spray process is concurrently under development to deposit promising materials on large areas, enabling inexpensive rapid application and reapplication on receivers in the field.
Current coatings are not suitable for the high temperatures and oxidative environments needed for power towers. This project takes an integrated approach to developing new materials with optimized optical properties and stability. Solution-based deposition methods allow rapid deposition and screening of coatings with intrinsic optical properties. Physical vapor deposition methods allow extremely fine control of the morphology, stoichiometry, and crystal structure, thereby controlling the resulting optical and thermal properties.
Publications, Patents, and Awards
At this time, this project does not have published articles, patents, or awards.
